OEM Part Number

6560954

Fit For the Following Models

For Bobcat Construction & Industrial(s) 1600

For Bobcat Skid Steer Loader(s) 542B, 543 (s/n 502412001-later, 511111001-later), 543B (s/n 502412001-later, 511111001-later), 553 (s/n 513011001-later, 516311001-later, 516411001-later), 630, 631, 632, 641, 642, 642B, 643, 645, 730, 731, 732, 741, 742 (s/n 501811001-later, 507423001-later), 742B (s/n 501811001-later, 507423001-later), 743, 743B, 743DS

For Bobcat Wheel Loader(s) 1600

Replaces Bobcat OEM Number(s) 6560954

Core Height (between tanks): 18.5"

Core Width: 7"

Core Thickness: 1.5"

Fins per Inch (FPI): 7

Made of steel tubes with aluminum fins to replace original steel version

Mounting Holes (center to center): 24.72" (628mm)

Fittings Center to Center: 21.97" (558mm)
